FF2470 performs 24-channel DSP beam filtering to steer the vertical radiation pattern, making column high directive and featuring main propagation lobe less dependent on the frequency.
FF2470 is equipped with 24 high quality, coaxial loudspeakers, each one mounting 4” neodymium woofer + 1’’ dome tweeter, capable to transmit perfect audio.
FF2470 uses 24 x 70 Wrms class-D audio amplifiers with excellent THD+N and high efficiency (90%) and completely protected against thermal over-load.
FF2470 mounts high-reliable, switching power supply (1290 W peak) with universal input (90 – 264 VAC).
FF2470 has analog line input and built-in Dante input both.
FF2470 setup comes easy throughout the AVE Line Array User Control PC software, via RS485 connection.
AVE Line Array User Control includes:
• Beam tilting/broadening control;
• Anti-Reverberation System ARS.
• Delay control;
• 8-biquads user equalizer with high/low shelving and parametric filters;
FF2470 cabinet is aluminum extrusion and it is designed and manufactured in Germany.
FF0870 performs 8-channel DSP beam filtering to steer the vertical radiation pattern, making column high directive and featuring main propagation lobe less dependent on the frequency.
FF0870 is equipped with 8 high quality, coaxial loudspeakers, each one mounting 4” neodymium woofer + 1’’ dome tweeter, capable to transmit perfect audio.
FF0870 uses 8 x 70 Wrms class-D audio amplifiers with excellent THD+N and high efficiency (90%) and completely protected against thermal over-load.
FF0870 mounts high-reliable, switching power supply (430 W peak) with universal input (90 – 264 VAC).
FF0870 has analog line input and built-in Dante input both.
FF0870 setup comes easy throughout the AVE Line Array User Control PC software, via RS485 connection.
AVE Line Array User Control includes:
• Beam tilting/broadening control;
• Anti-Reverberation System ARS.
• Delay control;
• 8-biquads user equalizer with high/low shelving and parametric filters;
FF0870 cabinet is aluminum extrusion and it is designed and manufactured in Germany.
FF1670 performs 16-channel DSP beam filtering to steer the vertical radiation pattern, making column high directive and featuring main propagation lobe less dependent on the frequency.
FF1670 is equipped with 16 high quality, coaxial loudspeakers, each one mounting 4” neodymium woofer + 1’’ dome tweeter, capable to transmit perfect audio.
FF1670 uses 16 x 70 Wrms class-D audio amplifiers with excellent THD+N and high efficiency (90%) and completely protected against thermal over-load.
FF1670 mounts high-reliable, switching power supply (860 W peak) with universal input (90 – 264 VAC).
FF1670 has analog line input and built-in Dante input both.
FF1670 setup comes easy throughout the AVE Line Array User Control PC software, via RS485 connection.
AVE Line Array User Control includes:
• Beam tilting/broadening control;
• Anti-Reverberation System ARS.
• Delay control;
• 8-biquads user equalizer with high/low shelving and parametric filters;
FF1670 cabinet is aluminum extrusion and it is designed and manufactured in Germany.
Axient Digital offers dual and quad receiver options that open the door to a full range of features, from high-performance RF to transparent digital audio.
The AD4Q Four-Channel Digital Receiver sets a new standard in spectral efficiency. Groundbreaking performance features include wide tuning, low latency, High Density (HD) mode, and Quadversity, ensuring solid performance in the most challenging RF environments. Networked control, AES3 + AES67 + Dante™ output, and signal routing options bring a new level of management and flexibility to your entire workflow.
Dante Audio Wallplate
| Maximum Analog Gain | 20 dB |
| Maximum Power Level | +8 dBu (Balanced) |
| Frequency Response | ±0 2 dB (20 Hz to 20 kHz) |
| THD+N | < 0 002% (1 kHz, +4 dBu) |
| Analog Background Noise | -97 dBu (A-weighted) |
| Dante Background Noise | -97 dBu (A-weighted) |
| Channel Isolation | 100 dB (1 kHz) |
| Input Impedance | 20k ohms (Balanced) |
| Output Impedance | 100 ohms (Balanced) |
| Phantom Power | 48 V |
| Interface | |
| Input Port | 2 Analog Audio (XLR) |
| Output Port | 2 Analog Audio (XLR) |
| Ethernet Port | 2 Dante Audio (RJ-45) |
| Power | |
| PoE Standard | IEEE 802 3af (PoE) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 5 W (peak power) |
| Enclosure | |
| Chassis Material | Faceplate: Metal; Back Box: Metal |
| Chassis Color | Faceplate: Black |
| Chassis Dimensions (Hight×Width×Depth) | 110×110×50 mm |
| Chassis Weight | 1 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante Audio Microphone
| Frequency Range | 80 Hz to 16 kHz |
| Sensitivity | -44 dB (±2 dB) |
| Interface | |
| Ethernet Port | 1 Dante Audio (RJ-45) |
| Power | |
| PoE Standard | IEEE 802 3af (PoE) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 15 W (peak power) |
| Enclosure | |
| Chassis Material | Metal |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 110×135×45 mm |
| Chassis Weight | 0 836 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante Wall Mount Speaker System
| System Power Efficiency | > 85% |
| Frequency Range | ±3 dB (70 Hz to 18 kHz) |
| Maximum SPL | 115 dB (1 m) |
| Nominal Sensitivity | 98 dB (1 W, 1m) |
| Nominal Coverage Angles (Horizontal×Vertical) | 100°×60° |
| Nominal Impedance | 8 ohms |
| Drivers | Woofer: 1×10”; Tweeter: 1×1” |
| Interface | |
| Ethernet Port | 1 Dante Audio (RJ-45) |
| Cascade Port | 1 Analog Audio (speakON) |
| Power | |
| Power Consumption | 140 W, 8 ohms |
| PoE Standard | IEEE 802 3at (PoE+) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 85 W (peak power) |
| Enclosure | |
| Chassis Material | Wood |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 463×310×220 mm |
| Chassis Weight | 7 75 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante Wall Mount Speaker System
| System Power Efficiency | > 85% |
| Frequency Range | ±3 dB (70 Hz to 18 kHz) |
| Maximum SPL | 114 dB (1 m) |
| Nominal Sensitivity | 97 dB (1 W, 1m) |
| Nominal Coverage Angles (Horizontal×Vertical) | 100°×60° |
| Nominal Impedance | 8 ohms |
| Drivers | Woofer: 1×8”; Tweeter: 1×1” |
| Interface | |
| Ethernet Port | 1 Dante Audio (RJ-45) |
| Cascade Port | 1 Analog Audio (speakON) |
| Power | |
| Power Consumption | 50 W, 8 ohms |
| PoE Standard | IEEE 802 3at (PoE+) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 85 W (peak power) |
| Enclosure | |
| Chassis Material | Wood |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 410×273×192 2 mm |
| Chassis Weight | 6 3 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante Wall Mount Speaker System
| System Power Efficiency | > 85% |
| Frequency Range | ±3 dB (70 Hz to 18 kHz) |
| Maximum SPL | 114 dB (1 m) |
| Nominal Sensitivity | 97 dB (1 W, 1m) |
| Nominal Coverage Angles (Horizontal×Vertical) | 100°×60° |
| Nominal Impedance | 8 ohms |
| Drivers | Woofer: 1×6 5”; Tweeter: 1×1” |
| Interface | |
| Ethernet Port | 1 Dante Audio (RJ-45) |
| Cascade Port | 1 Analog Audio (speakON) |
| Power | |
| Power Consumption | 30 W, 8 ohms |
| PoE Standard | IEEE 802 3af (PoE), IEEE 802 3at (PoE+) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 85 W (peak power) |
| Enclosure | |
| Chassis Material | Wood |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 342×223×163 mm |
| Chassis Weight | 5 9 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante POE Power Module
| System Power Efficiency | > 85% |
| SNR | 100 dB |
| Background Noise | < 300 uV |
| Interface | |
| Input Port | 1 Dante Audio (RJ-45) |
| Output Port | 1 Analog Audio (Terminal Block) |
| Power | |
| PoE Standard | IEEE 802 3at (PoE+) |
| PoE Power | 60 W, 8 ohms; 100 W, 4 ohms (peak power) |
| Enclosure | |
| Chassis Material | Metal |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 147 2×60×24 8 mm |
| Chassis Weight | 0 5 kg |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante 4 5” Column Speaker
| Frequency Range | ±4 dB (90 Hz to 19 kHz) |
| Nominal Sensitivity | 96 dB |
| Nominal Coverage Angles (Horizontal×Vertical) | 110°×70° |
| Drivers | Woofer: 4×4 5”, Tweeter: 1×1 35” |
| Interface | |
| Ethernet Port | 1 Dante Audio (RJ-45) |
| Cascade Port | N/A |
| Power | |
| Power Consumption | 60 W, 8 ohms |
| PoE Standard | IEEE 802 3af (PoE), IEEE 802 3at (PoE+) |
| PoE Signaling | Powered Device (PD) |
| PoE Power | 85 W (peak power) |
| Enclosure | |
| Chassis Material | Metal |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 750×180×160 mm |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Dante POE Power Module
| System Power Efficiency | > 70% |
| SNR | 84 dB |
| Background Noise | < 130 uV |
| Interface | |
| Input Port | 1 Dante Audio (RJ-45) |
| Output Port | 1 Analog Audio (Terminal Block) |
| Power | |
| PoE Standard | IEEE 802 3bt (4PPoE) |
| PoE Power | 85 W, 8 ohms; 120 W, 4 ohms (peak power) |
| Enclosure | |
| Chassis Material | Metal |
| Chassis Color | Black |
| Chassis Dimensions (Hight×Width×Depth) | 162×80×42 mm |
| Environment | |
| Operating Temperature | +32 to +104 °F (0 to +40 °C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Compliance | |
| Regulatory Compliance | FCC, CCC, CE, RoHS |
Designed for flypack and OB audio applications, the S500m console delivers maximum control in a light weight and reduced form factor, whilst offering the same flagship performance and surface configurability as the S500.
The new ELAN® Digital IP-Enabled Multi-Room Audio System featuring Dante® audio networking is the next generation of Multi-Zone Audio. This new intelligent audio system delivers exceptional quality with the flexibility to scale from a single chassis to multiple chassis and up to 64 zones. The comprehensive line includes a Multi-Zone Audio Matrix, Multi-Zone Audio Extender, Multi-Zone Pre-Amp Audio Matrix, Local Audio Source Preamp and a Network Audio Card.
EL-IPD-MTX-8CH is a Multi Zone Audio Matrix
The new ELAN® Digital IP-Enabled Multi-Room Audio System featuring Dante® audio networking is the next generation of Multi-Zone Audio. This new intelligent audio system delivers exceptional quality with the flexibility to scale from a single chassis to multiple chassis and up to 64 zones. The comprehensive line includes a Multi-Zone Audio Matrix, Multi-Zone Audio Extender, Multi-Zone Pre-Amp Audio Matrix, Local Audio Source Preamp and a Network Audio Card.
EL-IPD-PRE-SSI is a Local Audio Source
The new ELAN® Digital IP-Enabled Multi-Room Audio System featuring Dante® audio networking is the next generation of Multi-Zone Audio. This new intelligent audio system delivers exceptional quality with the flexibility to scale from a single chassis to multiple chassis and up to 64 zones. The comprehensive line includes a Multi-Zone Audio Matrix, Multi-Zone Audio Extender, Multi-Zone Pre-Amp Audio Matrix, Local Audio Source Preamp and a Network Audio Card.
EL-IPD-AMP-EXT is a Multi Zone Audio Extender
PacketAV® Duet has been nothing short of a paradigm shift for networked AV. True convergence; a single platform to support Dante™/AES67 and Video over IP. Building on their success and wide adoption, the next generation of PacketAV® Duet endpoints continue to provide powerful 4K UHD Video and Dante™/AES67 Audio – now over a single Gigabit Ethernet port, with USB-C connectivity and other enhanced features.
Visionary’s PoE 4K UHD over IP cinema quality, ultra-low latency [~1 frame - visually lossless], encoders and decoders bypass the constraints of traditional switch matrix distribution systems by continuing to harness the flexibility and scalability of converged IP networks.
With the growing demand for 4K UHD video, professional AV designers and IT directors – in an increasingly converged AV/IT environment – have been using Visionary’s products as an alternative to conventional distribution systems.
PacketAV® Duet has been nothing short of a paradigm shift for networked AV. True convergence; a single platform to support Dante™/AES67 and Video over IP. Building on their success and wide adoption, the next generation of PacketAV® Duet endpoints continue to provide powerful 4K UHD Video and Dante™/AES67 Audio – now over a single Gigabit Ethernet port, with USB-C connectivity and other enhanced features.
Visionary’s PoE 4K UHD over IP cinema quality, ultra-low latency [~1 frame - visually lossless], encoders and decoders bypass the constraints of traditional switch matrix distribution systems by continuing to harness the flexibility and scalability of converged IP networks.
With the growing demand for 4K UHD video, professional AV designers and IT directors – in an increasingly converged AV/IT environment – have been using Visionary’s products as an alternative to conventional distribution systems.
Dante Network Audio Card for ELAN network amplifiers.
The MX Series have been designed to offer a uniquely simple solution to the long-standing problem of routing of multiple mixing consoles outputs to a speaker system / system processor. Handling up to 36 inputs in 2U across analogue, AES and Dante networks, these are arranged in sets of four (to typically support Left-Right-Front Fill and Sub feeds from an individual console). All AES inputs have SRC. There is one set of four outputs, available simultaneously across analogue, AES and Dante networks with Word Clock output sync available on AES.
The MXE5 is the first member of the MXE matrix mix engine series. The 24 x 24 crosspoint performance audio matrix offers both routing and mixing functionalities, with 12 analog mic/line inputs and eight line outputs. At the same time, the MXE5 serves as a communications hub for all IP-based peripherals and provides comprehensive supervision of all system-wide commands.
With the latest V2.6 S-Series console fitted with a DMI-DANTE64@96 card providing 64 channels in and 64 channels out at both 48kHz and 96kHz, the package also includes three Dante enabled A168D STAGE I/O offering 48 mic inputs across multiple stages or auditoriums to deliver incredible sonic quality and flexibility.
With the latest V2.6 S-Series console fitted with a DMI-DANTE64@96 card providing 64 channels in and 64 channels out at both 48kHz and 96kHz, the package also includes three Dante enabled A168D STAGE I/O offering 48 mic inputs across multiple stages or auditoriums to deliver incredible sonic quality and flexibility.
The DiGiCo DMI-DANTE64@96 allows 64 channels in and 64 channels out at both 48kHz and 96kHz. It has a Primary and a Secondary port, both of which are Ethercon ports, and an RJ45 Control port. The card has two modes that can be changed in Dante Controller. In Switched Mode, the three ports are switched together. In redundant mode, the Control and Primary ports shall be switched together and work as a redundant pair with the Secondary port, each having separate IP addresses so that if the primary connection fails, the secondary connection will take over.
Third party applications that use Dante Ready™ allow customers to purchase and activate Dante audio channels after installation using the Dante Activator tool in Dante Controller 4.5 or higher. Dante Activator is tied to an active Audinate user account and accepts standard credit card payments.
Activation instructions:
