Apantac DA-SDI-DE12G is a 12G SDI de-embedder with loop outs. On-board LED meters for displaying audio presence and LED indicator for displaying of group association.
Features:
De-embeds 12G/3G/HD/SD-SDI with 16 channels of audio
Outputs 8 AES pairs or 16 mono analog audio
Specifications:
Front View:
RS232 for FW upgrade
Analog audio monitoring output
AES audio monitoring output
Rotary selector for analog and AES monitoring audio pair
DB25 for analog audio / AES audio breakout cable
12V DC power cascading output and power input
Rear View:
SDI input
Optional Fiber SFP input
SDI loop out and HDMI output
Inputs: 12G/3G/HD-SDI
Outputs: 1 x loop out
Audio: De-embeds 16 channels of AA, 8 pairs of AES, balanced or unbalanced
Power: 12V 1A
Weight: 1Lbs (0.45kg)
Dimension (WxDxH): 2.44 x 4.45 x 1.57" (62 x 113 x 40mm)
Cobalt® introduces the ARIA OG-AUD2-DANTE card in a openGear® form factor. The COBALT ARIA OG-AUD2-DANTE is a 2x channel unit with 12G SDI and DANTE/ AES/MADI which can simultaneously embed and de-embed audio between SDI, DANTE, AES and MADI with flexible routing and mixing. This card also includes a built-in frame sync. This openGear® card features two gigabit Ethernet ports, and a 32x32 Dante channel matrix mixer. The Cobalt ARIA OG-AUD2-DANTE — High-density, compact openGear® card-based solution, with multiple devices is able to be combined into a single frame for multi-channel operation, as well as offering the standard features of redundant hot-swappable power supplies and hot-swappable cards. Free DashBoard™ software for remote control and configuration.
With StudioEdge, broadcasters and production teams can seamlessly introduce remote guests from every major video conferencing platform, including Microsoft Teams, Skype, and Zoom into productions, optimized with ground-breaking AI technology. Through broadcast-grade outputs including SDI, NDI, and ST 2110, StudioEdge enables seamless integration into video production systems, such as Ross, Grass Valley, Vizrt, Avid, and many more.
Utilizing built-in, industry-best QuickLink StudioCall technology, remote guests are seamlessly integrated with Teams, Zoom, and Skype calls. StudioEdge allows users to create real-time group conversations, panel discussions, and live interviews as it can manage any combination of remote guests from around the world, optimized with AI technology, with direct communication and chat support for guidance. The system offers a browser-based remote-control interface via QuickLink’s cloud platform, from any global location. QuickLink StudioEdge technology takes remote guest integration to unprecedented heights by utilizing QuickLink’s renowned remote-control expertise over production elements.
iSmart Video PBC-120 – PTZ camera equipped with a 4/3-inch CMOS sensor capable of transmitting high-definition video with a resolution of 200,000 pixels. With 20x optical zoom and support for simultaneous video output via 12G-SDI and 3G-SDI.
Features of iSmart Video PBC-120
4/3” CMOS sensor delivers professional-grade image detail and color;
20x optical zoom, maximum HFOV 71°;
Built-in optical stabilization;
Wide output interfaces such as 12G-SDI, 3G-SDI, HDMI 2.0, USB 3.0, RJ45, etc.;
Support for popular protocols: SRT, NDI HX3, Dante AV-H;
Additional support for Full NDI and Dante AV-Ultra;
Built-in Free-D protocol for professional virtual studios;
Additional dual-camera design to realize powerful AI functions;
iSmart Video PVC -230 is a PTZ camera equipped with two 1/1.8-inch dual cameras, 8.4MP, and can output up to 4KP60 video frames. 12G-SDI is optional and supports NDI HX3, Dante AVH, SRT.
Features of iSmart Video PVC-230
Dual camera design with maximum 4K 60 resolution with full view and close-up viewing at the same time;
1/1.8” 30 optical zoom lens is suitable for large scales;
Fixed full view lens with wide field of view, no distortion;
Rich interfaces: 3G-SDI, HDMI 2.0, USB 3.0, RJ45, etc.
Support SRT, NDI HX3, Dante AV-H, RTSP, RTMP, RTMPR, ONVIF, VISCA OVER IP, etc.;
Industry-leading AI capabilities including multiple tracking modes, gesture control, etc.;
The HVS-Q12 is a powerful and compact 4RU production switcher designed for both HD and 4K workflows. It supports up to 60 inputs and 32 outputs in HD, and up to 42 inputs and 23 outputs in 4K. Each ME offers up to 8 keyers in 3G/HD-SDI, providing advanced flexibility for live production environments.
The switcher is equipped with key FOR-A features, including HDR/SDR conversion, up/down conversion, and audio pass-through—even when Frame Sync is active. For IP integration, the HVS-Q12 supports both NDI® and Dante interfaces, streamlining system design and enhancing workflow efficiency. With support ranging from 3G-SDI to 12G-SDI, the HVS-Q12 can be tailored to meet a wide range of application needs.
The Spectera Base Station is a 1RU hardware device that provides up to 64 channels (32 in/32 out) and utilizes up to two wideband RF carriers to accommodate all of the unit’s wireless transmission.
It features redundant Dante and optional redundant Madi, assuring seamless integration into your audio network. Additional antennas can be added for redundancy, extended zone coverage, or additional spectrum capacity.
The Spectera Base Station supports sample rates of 48 kHz and 96 kHz and features individual sample rate converters for all audio interfaces and wordclock I/O. Base Station must be activated with license per region.
19’’ 1 RU Base Station with redundant power supplies
Provides up to 64 channels (32 in / 32 out) and allows for up to two independent wideband RF carriers in UHF or 1G4 (6 or 8 MHz) – country specific per region license
4 ethernet antenna ports for redundancy, extended zone coverage, and additional spectrum usage
Redundant Dante® audio interface
Two optional slots for redundant MADI (OM or BNC)
Sample rates of 48 kHz and 96 kHz
Individual sample rate converters for all audio interfaces
Wordclock I/O BNC
Synchronized clock for all audio over RF allows 3D recordings and playback
Adjustable RF power from 10 – 100 mW (country specific)
RJ45 network interface for full remote control with secured interface
11 Audio Link modes with selectable audio codecs (OPUS, SeDAC) or PCM
Secure transmission of confidential content using AES 256 encryption
Future expansion via Cascade port
Selective headphone output with volume control on front panel
OLED display, jog wheel navigation, and rugged metal housing
Base Station activation via LinkDesk: Spectera license defines respective frequency spectrum per region (license sold separately)
The DZR10-D is a Dante-equipped 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 137dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR10-D realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
2-way powered loudspeaker with a 2” HF and a 10" LF
Maximum 137dB SPL and 44Hz-20kHz frequency range is ideal for today’s audio engineering demands
High power 2000W Class-D amplifier module
96kHz DSP and FIR filter for true high-resolution sound with super low latency
Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
D-Contour and highly reliable protection circuits
Floor monitoring setting
Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
Optional speaker cover(SPCVR-DZR10)
Rotatable horn and variety of U-bracket options (UB-DZR) for rigging allow for very flexible setup and speaker placement
The DZR12-D is a Dante-equipped 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 139dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR12-D realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
2-way powered loudspeaker with a 2” HF and a 12" LF
Maximum 139dB SPL and 39Hz-20kHz frequency range is ideal for today's professional audio demands
High power 2000W Class-D amplifier module
96kHz DSP and FIR filter for true high-resolution sound with super low latency
Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
The DZR15-D is a Dante-equipped 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 139dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR15-D realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
2-way powered loudspeaker with a 2” HF and a 15" LF
Maximum 139dB SPL and 34Hz-20kHz frequency range is ideal for today's professional audio demands
High power 2000W Class-D amplifier module
96kHz DSP and FIR filter for true high-resolution sound with super low latency
Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
The DZR315-D is a Dante-equipped three-way bi-amped powered loudspeaker and is the most powerful model in the DZR Series producing a maximum 143dB SPL with supreme clarity. Best-in-class SPL performance, sophisticated DSP processing, unrivaled low-frequency sound reproduction—the DZR315 delivers on all fronts realizing a truly professional sound delivered with a level of power that belies its compact, lightweight design. Ideal for use in a front of house main PA, it also includes integrated M10 rigging points for suspended applications.
3-way powered loudspeaker with a 2” HF, an 8 ” MF and a 15" LF
Maximum 143dB SPL and 31Hz-20kHz frequency range is ideal for FOH main PA
High power 2000W Class-D amplifier module
96kHz DSP and FIR filter for true high-resolution sound with super low latency
Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
D-Contour and highly reliable protection circuits
Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
The OIP-N40E is an AV bridge that encodes HDMI video, USB-C and DisplayPort signals to IP formats at very low latency. The device is Dante ready, enabling seamless integration with Dante audio and Dante AV-H video networks. The Dante Controller app allows users to add a Dante license, enabling it to encode video to Dante AV-H and transmit Dante audio signals bi-directionally.
• Dante Ready
• Low latency HDMI, USB and DisplayPort HD transmission
• Supports PoE and USB power for easy installation
• Dual Tally lights (360°)
Auri™ is the first complete assistive listening system for professional installation utilizing Auracast™ broadcast audio. Auri is an ideal public solution, addressing hearing assistance and personal listening preferences. Auri enables end users to use their Auracast™ compatible device or a venue-provided receiver to enhance their audio experience.
Key features include:
Multi-channel Broadcast
Network Management
Open or Secure Audio
Compatible with Auracast™ enabled devices, such as hearing aids, headphones or earbuds
The Auri TX2N-D is an Auracast™ Broadcast Audio transmitter. It features balanced analog mic/line inputs and 2 channels of Dante, supporting mono, stereo, or dual mono configurations. Used with Auri RX1 Receivers it creates a fully compliant next generation assistive listening solution.
The WL64-4 rack mount Audio over IP (AoIP) audio monitoring unit operates in conjunction with the Nixer Remote iPad® App. The WL64-4 provides a “base unit” for the monitoring and mixing of AoIP sources from a Dante or Ravenna network. Each unit is configured at time of purchase to be Dante or Ravenna. The Nixer Remote App allows audio to be wirelessly streamed to an iPad® for local monitoring, freeing the Operator from a dedicated hardware front panel display and equipment rack. As standard, each WL64-4 can have four iPads connected wirelessly and each Operator can select and listen to sources independently as well as creating their own individual mixes. Each iPad is able to stream audio wirelessly to the internal speakers, headphone output or via Bluetooth. The audio can be selected in a simple “Listen” or “Mix” mode.
The supplied mounting plate and paintable cover allow discreet placement on the ceiling or wall in boardrooms and conference rooms where low visibility is preferred.
Two-way wireless transmission allows for remote control of audio and transmission of a secondary program audio to each transmitter.
Multiple units can be combined to support configurations of up to 40 compatible channels and 80 in Europe and select countries (double in HD mode).
Supports standards-based security protocols to manage access and protect data, including 802.1x, secure boot/storage, and AES encryption for wired and wireless control and audio data.
Selectable RF output power to allow optimize spectrum usage by selecting the appropriate wireless output power for the desired operating range.
Diagnostic LEDs offer easy visual reference to system activity and indicate power, wireless connection, and network audio status.
A CUI can be accessed on a PC connected to the same network enabling access to all device properties for optimization and user specific settings.
The Microflex® Wireless neXt system is more than a wireless microphone. It’s an all-in-one audio solution for hybrid classrooms, training rooms, and lecture halls that provides superior audio for conferencing and presentations at the same time. Despite its comprehensive feature set, the MXW neXt system is easy to set up in minutes.Bluetooth functionality not currently available.
Current Microsoft Teams and Zoom Rooms certification solutions include MXWAPXD2, MXW6X, and MXN5W-C.
Multichannel PoE+ powered amplifier designed for speech and program audio reproduction in meeting rooms. The Microflex® Conferencing amplifier is designed for conferencing with clear, intelligible audio. When used with Microflex Ecosystem microphones, DSP, and loudspeakers, they deliver room-filling sound, quick installation in a variety of room types, and the efficiency of a single-source solution.
The MA-2.1200 is a compact 2-channel digital amplifier with a 4 × 2 routing matrix. It forms a powerful and reliable component in your fixed installation and is extremely flexible and cost-efficient. The integration in media controls and audio networks is possible without difficulty and the configuration can also be done very easily via a USB-C socket with Fohhn Audio Soft.
Main features
Output power: 2 × 1200 W / 4 ohms / 100 V / 70 V
Available in two variants: With Analog Inputs (MA-2.1200 ANA) or Dante Input (MA-2.1200 DAN)
Compact and light: 1 U, 5.2 kg
Mounting brackets for rack included
Two freely programmable switching contacts
With Fohhn Airea connection
Can be remotely operated and controlled over Fohhn Net
Q-SYS Plugin available in combination with Fohhn NA-4 or ABX-6
Temperature controlled, low noise fan
Auto Power Save for minimum standby power requirements
Fohhn speaker presets ensure maximum safety, reliability and excellent sound quality
The MA-4.600 is a compact 4-channel digital amplifier with a 4 × 4 routing matrix. It is ideal for smaller and medium-sized projects and it's extremely flexible and cost effective. It can be easily integrated into media controls and is effortlessly configured with the Fohhn Audio Soft via a USB-C socket.
Main features
Output power: 4 × 600 W / 4 ohms / 100 V / 70 V
Available in two variants: With Analog Inputs (MA-4.600 ANA) or Dante Input (MA-4.600 DAN)
Compact and light: 1 U, 5.2 kg
Mounting brackets for rack included
Two freely programmable switching contacts
With Fohhn Airea connection
Can be remotely operated and controlled over Fohhn Net
Q-SYS Plugin available in combination with Fohhn NA-4 or ABX-6
Temperature controlled, low noise fan
Auto Power Save for minimum standby power requirements
Fohhn speaker presets ensure maximum safety, reliability and excellent sound quality
The MA-4.100 is a compact 4-channel digital power amplifier for media applications and small sound system solutions. The DSP amplifier with a 4 × 4 matrix is ideal for, e.g. equipping conference and training rooms as well as for installation in media steles. It can be easily integrated into media controls via Dante and is effortlessly configured with the Fohhn Audio Soft via a USB-C socket or Ethernet.
Main features
4 × 100 W peak / 4 ohms
New: Dante and Analog Inputs (no variants anymore)
Compact dimensions: 9.5" / 1 U, 170 mm installation depth
Mounting brackets for rack included
Switchable phantom power on each input channel
Two freely programmable switching contacts
Can be remotely operated and controlled over Fohhn Net
Q-SYS Plugin available
Temperature controlled, low noise fan
Auto Power Save for minimum standby power requirements
Fohhn speaker presets ensure maximum safety, reliability and excellent sound quality
FS-200 is an extra slim, active line source speaker with Fohhn Beam Steering Technology. This allows the control of the sound beam by turning the mouse wheel. The Focus Slim series makes this world-renowned Fohhn technology attractive for smaller and more price-sensitive projects. Thanks to the crystal-clear speech transmission, the systems are ideal for high class conference rooms, lecture halls and small to medium sized churches.
Main features
16 × 2.5" broadband chassis with coaxial Fohhn diffraction waveguides
16 integrated Fohhn DSP amplifiers with 75 W each
123 dB max. SPL
Integrated bass reflex system
Very wide horizontal dispersion of 140°
Vertical dispersion controllable in real time via Fohhn Audio Soft
Vertical beam width: 0° to 90°, sound inclination angle: -40° to +40° (adjusted in 0.1° increments)
Acoustic centre displaceable over entire line length
Fohhn Two Beam Technology (two independent dispersion beams)
Fohhn Side Lobe Free Technology (suppression of side lobes)
FS-150 is an extra slim, active line source speaker with Fohhn Beam Steering Technology. This allows the control of the sound beam by turning the mouse wheel. The Focus Slim series makes this world-renowned Fohhn technology attractive for smaller and more price-sensitive projects. Thanks to the crystal-clear speech transmission, the systems are ideal for high class conference rooms, lecture halls and small to medium sized churches.
Main features
12 × 2.5" broadband chassis with coaxial Fohhn diffraction waveguides
12 integrated Fohhn DSP amplifiers with 75 W each
121 dB max. SPL
Integrated bass reflex system
Very wide horizontal dispersion of 140°
Vertical dispersion controllable in real time via Fohhn Audio Soft
Vertical beam width: 0° to 90°, sound inclination angle: -40° to +40° (adjusted in 0.1° increments)
Acoustic centre displaceable over entire line length
Fohhn Two Beam Technology (two independent dispersion beams)
Fohhn Side Lobe Free Technology (suppression of side lobes)
FS-110 is an extra slim, active line source speaker with Fohhn Beam Steering Technology. This allows the control of the sound beam by turning the mouse wheel. The Focus Slim series makes this world-renowned Fohhn technology attractive for smaller and more price-sensitive projects. Thanks to the crystal-clear speech transmission, the systems are ideal for high class conference rooms, lecture halls and small to medium sized churches.
Main features
8 × 2.5" broadband chassis with coaxial Fohhn diffraction waveguides
8 integrated Fohhn DSP amplifiers with 75 W each
117 dB max. SPL
Integrated bass reflex system
Very wide horizontal dispersion of 140°
Vertical dispersion controllable in real time via Fohhn Audio Soft
Vertical beam width: 0° to 90°, sound inclination angle: -40° to +40° (adjusted in 0.1° increments)
Acoustic centre displaceable over entire line length
Fohhn Two Beam Technology (two independent dispersion beams)
Fohhn Side Lobe Free Technology (suppression of side lobes)
Third party applications that use Dante Ready™ allow customers to purchase and activate Dante audio channels after installation using the Dante Activator tool in Dante Controller 4.5 or higher. Dante Activator is tied to an active Audinate user account and accepts standard credit card payments.
