Product Information
Features
- Microphone/line input: 4 x balanced audio inputs.
- Line output: 4x balanced audio output.
- Dante：1 x Dante ® Ethernet interface connector, supporting POE power supply; 1 x Dante ® Ethernet interface connector; Two interfaces implement data exchange function.
- DC 12V: A DC connector used for connecting DC 12V1A power adapters.
- Input interface: 4-channel microphone/line input,
- 3-pin green wiring terminal Output interface: 4-channel line output,
- 3-pin green terminal block Gain: Input: 0~+48dB, 6dB per step;
- Output: -60~0dB,
- 1dB per step Maximum level: Input:+18dBu @ 0dB input gain;
- Output:+18dBu @ 0dB output gain
- Input impedance:>1.8k Ω Effective
- Input Noise (EIN): -119dB @ 48dB gain
- Effective output noise:<-79dBu @ 0dB gain
- Harmonic distortion:<0.05%
- Sampling rate: 44.1kHz or 48kHz
Specifications
- Dante Ch: 4x4
- Bit Depth: 24-bit
- Sample Rate: 44.1kHz, 48kHz
- AES67 Enabled
