MONISMS - MNS-AMP260AC

MONISMS – MNS-AMP260AC

Product Information

The MONISMS MNS-AMP260AC Dante Audio Amplifier is a compact power amplifier module that drives small 4-8Ω speakers (Ceiling Speaker, In-wall Speaker, Pendant Speaker Column Speaker etc.)

The MONISMS MNS-AMP260AC Dante Audio Amplifier is a compact power amplifier module that drives small 4-8Ω speakers (Ceiling Speaker, In-wall Speaker, Pendant Speaker Column Speaker etc.) The MONISMS Dante Amplifier has two outputs, each with 30W of power into an 4-8Ω load, This makes the module ideal for powering small areas consisting of only a few low power speakers.

The module’s audio input is via an Ethernet audio network, allowing the use of the DANTE/ AES67 audio network protocol.

MNS-AMP260AC MAX power 2*30W, Which build-in AC 100-240V power module.

Dante Audio Amplifier can be mounted on a DIN rail or screwed onto a panel or wall for easy installation in a remote closet near the speaker area.

Voltera – D-4800-4M

Audio DSP and amplified loudspeaker controller; 4 channels sharing 4800W with Dante and AVB. Key Features

Powerful onboard DSP with ample headroom for large systems – the equivalent of a TesiraFORTÉ for Tesira custom processing and hosting of expanders
4 class D channels sharing 4800 watts
Power sharing provides up to 75% of total power or 3600 W through any single channel
High peak voltage output capability: 237 Vpk
Each channel can drive low impedance (2.7, 4, 8, and 16 ohm), 70V, or 100V
Each model supports AVB, Dante, and AES67
Accurate raised cosine EQ for the entire frequency band
Group-controlled raised cosine EQ making it attractive for tuning large systems
Comprehensive amplifier limiter scheme avoids protective mutes and shutdowns
Processor can be sustained through POE – no main power required and no reboots
Support for failover-to-analog from networked audio input operation
5-year warranty
Compliant with the US Trade Agreement Act (TAA)
Biamp Workplace Ready

Amplifiers

48kHz-96kHz
AES67 Enabled

See the product

Soundking

Soundking – AKF1600

The AKF1600 is an intelligent amplifier with 4 inputs/outputs and a built in high performance DSP.

Amplifiers

See the product

Williams AV

Williams Sound – DL207 NET D

The Digi-Loop’s amplifier design offers either single or dual 9.5 A rms loop outputs for perimeter loop(s), single array(s), dual loop, or phased-array configuration. A 70-100 V input provides connection to a distributed speaker/paging system, ensuring announcements are heard by loop users. Digi-Loop is definitely state-of-the-art – the first of its kind to maximize modern amplifier technology. Its network-control capability provides seamless, remote system set-up, operation and monitoring via laptop or tablet. DSP audio processing offers flexible, powerful software control of mixing, equalization, compression and more. Powerful Class D, pulse-width amplifiers maximize efficiency. The Digi-Loop’s amplifier design offers either single or dual 9.5 A rms loop outputs for perimeter loop(s), single array(s), dual loop, or phased-array configuration. A 70-100 V input provides connection to a distributed speaker/paging system, ensuring announcements are heard by loop users. system includes (1) PLA DL207 NET D Loop Amplifier (1) WLC 004 Line Cord (US) (1) IDP 009 ADA Wall Plaque (t-coil)

Amplifiers

Dante Ch: 2 In
24-bit

See the product
