E-DANTE64-HX is a Dante interface card for the Eclipse HX matrix systems (Omega, Median and Delta). It supports DANTE and is AES67 compatible, allowing users to transport up to 64 channels of high quality audio to multiple Dante-enabled devices using standard Ethernet network infrastructure.
E-Dante64-HX provides Eclipse HX with 16, 32 or 64 channels of low latency, high quality AoIP interconnection. It supports all standard sample frequencies for professional use, including a 96kHz/32-channel option.
Other E-Dante64-HX Features:
- Channel quantity, health and sample rate indicators
- Primary and secondary RJ-45 or fiber connections
- Port label data exchange to intercom panel keys
- Up to 64 ports per card; VOX on all 64 channels
- Channel labels carried over from 3rd party devices
- Optional SFP fiber interface fitted on both primary and secondary network interfaces
- Maximum of 7 cards per frame
The Eclipse HX Configuration Software (EHX) can enable intercom panels to display each Dante Controller channel label or the label of the current audio source routed to the channel.
