80-CHANNEL CONFIGURABLE AD/DA INTERFACE
Simply put, the B80 MOTHERSHIP has redefined digital recording. For anyone who has felt that digital recording has been lacking soul, warmth and musicality, the MOTHERSHIP is the answer. Building on the technology of the two-channel B2 BOMBERS, the MOTHERSHIP was forged from BURL AUDIO’S deep dedication to analog class-A circuitry.
Pushing the boundaries once again, the B80 MOTHERSHIP AD/DA converter has up to 80 analog channel capability. Using a card based system, and a heavy duty 4U chassis, the B80 MOTHERSHIP employs 10 card slots with 2, 4 and 8 channel AD/DA cards, all with the B2 quality signal path.
B80 MOTHERSHIP Features:
- 4U main chassis
- BMB1 (DigiLink) motherboard
- BMB2 (MADI) motherboard
- BMB3 (Dante) motherboard
- B1 BNC Word Clock In
- 2 BNC Word Clock Out
- 10 card slots
- All slots accept AD/DA, AES, MADI and BCLK
- 2, 4, and 8 channel analog cards
BAD4 Features:
- 44.1k Hz to 192k Hz, 24 bit, 4 channel ADC
- Exact same circuit path as B2 BOMBER ADC
- Proprietary, high definition, BURL AUDIO BX1 transformer input
- All class-A, discrete transistors signal path with zero feedback, zero capacitors
- 4 XLR connectivity
BDA8 Features:
- 44.1k Hz to 192k Hz, 24 bit, 8 channel DAC
- Circuit path based on B2 BOMBER DAC
- Latest BURL AUDIO BOPA2, OP-AMP
- All class-A, discrete transistors signal path zero capacitors
- D-sub DB-25 connectivity
BCLK Features:
- 9 Word Clock Outputs (8 BNC, 1 AES)
- Two independently programmable banks
- Extremely stable, low jitter clock
- Up to 92 Word Clock outputs in 1 unit
