Antelope Audio - Galaxy 64

Antelope Audio – Galaxy 64

Product Information

Antelope Audio’s first Dante interface is also the world’s first 64-channel AD/DA converter. Featuring all industry-standard analog and digital I/O within a 2U rack space, including 64 channels of analog in and 64 channels of analog out, Thunderbolt™ 3, DANTE, AES/EBU, HDX and MADI, the GALAXY 64 is equipped to handle all audio going in and out of your production facility or live venue.

The GALAXY 64 is a Synergy Core interface running both ARM DSP + FPGA chips, all in custom configurations, processing tens of input/output audio streams, and hundreds of low latency studio effects, all without burdening your CPU. With a total of 12x ARM DSP + 3x FPGA units on-board, a single GALAXY 64 can handle large sessions with hundreds of FX instances applied to each individual project, while employing a 3rd FPGA chip to process the routing matrix and manage conversion.

Designed for world class studio recording, live venues, post-production, broadcast, large-scale scoring, and other enterprise applications, GALAXY 64 fits 64 channels of all-encompassing connectivity, class leading signal processing, and rock-solid reliability inside a single 2U rackmount unit.

SSL – X-Light Bridge

For the touring market, a new 1U X-Light Bridge interface designed to be deployed within stage I/O racks, features a fully redundant pair of X-Light connections using Neutrik opticalCON Quad format connectors on the front panel. For the touring market, a new 1U X-Light Bridge interface designed to be deployed within stage I/O racks, features a fully redundant pair of X-Light connections using Neutrik opticalCON Quad format connectors on the front panel. On the rear panel there are two redundant pairs of Neutrik etherCON format Dante connections for audio and control distribution. Up to eight SB 32.24 stageboxes can now be connected via a pair of network switches to a single X-Light Bridge redundantly at 96 kHz with gain control of each input. There are no big workflow changes either! X-Light Bridge provides a seamless I/O boost for the user, as the routing process in the console interface is exactly the same via the X-Light Bridge as it is via the existing local Dante Expander Module. This includes the ability to configure the X-Light channel capacity as Virtual Tie Lines, for routing in Dante Controller, or as Dual Domain Routes for seamless routing and control from console channels.

I/O Interfaces

See the product

CTP Systems

CTP Systems – DIO1600

The DIO1600 is a Dante enabled interface converting sixteen analogue line level inputs and sixteen analogue line level outputs to the audio network. All inputs and outputs have adjustable gain from +12dB to -12dB. The XLR version may be specified with XLRs on the front, network connections on the rear or XLRs on the rear, network connections on the front. It can also be supplied in a 1RU format with Tascam standard audio connections similar to the DIO1616MA below. Network connections may be copper and/or fibre via two SFPs and the unit includes secondary ports for network redundancy. The DIO1600 is PoE enabled so may be operated without a mains supply if required. The unit also has a 100-240V AC mains inlet and also supports 12 volt operation so may be effectively used with a redundant power supply. All level controls are adjusted using the built in web server. The unit will operate at sample rates of 48kHz and 96kHz and may also be used in AES67 mode.

I/O Interfaces

See the product

Inter-M

Inter-M – DAC-288

The DAC-288 is a digital audio transport system utilizing Audinate’s DanteTM network audio solution. The DAC-288 connects to your network with a single Ethernet cable. It offers eight channels (2 mic/line selectable) of line-level analogue in and out, using precision 24-bit A-D and D-A conversion for superb audio performance, and 119dB dynamic range at sample rates up to 192kHz. This product is used as the audio matrix, each having eight inputs, where you can send uncompressed audio with low latency using standard TCP/ IP Ethernet network.

I/O Interfaces

See the product
