ACM – 335

Microphones

More Details

Similar Products

201991817125
  • BARE

BARE – Microphone System

Features
1. Advanced modular design, four groups of receiving modules, each group has a built-in independent CPU processing system to complete audio processing and transmission.
2. Ultra-high-bandwidth UHF 600MHZ-700MHZ, suitable for occasions that require a large number of microphones, making it easy to form a wireless conference microphone system.
3. Superb reception, overcome long distance and complicated field environments.
4. Use Ethernet cable to connect directly to the network-no need to add and solder audio cables.
5. Can control Dante routing and settings through a computer
6. The entire scalable Dante system has 512 two-way audio channels
7. Both the network volume and the receiver volume can be adjusted separately.
Technical parameters:
IF frequency: first IF: 110MHz, second IF 10.7MHz
wireless interface: BNC / 50 ohm
sensitivity: 12 dB (80dBS / N )
Sensitivity adjustment range: 12-32 dB
spurious suppression: ≥75dB
Maximum output intensity: +10 dBV
Frequency range: 600-700MHz
Modulation mode: FM
adjustable range: 50MHz
Number of channels: 100 or 200)
Channel interval: 250 KHz
frequency stability: within ± 0.005%
dynamic range: 100dB
maximum frequency deviation: ± 45KHz
audio response: 80Hz-18KHz (3dB)
comprehensive signal-to-noise ratio:> 105dB
Comprehensive distortion: ≤0.5%
Working temperature: -10 ℃ ~ + 40 ℃

    Microphones
See the product
audix-M55WD
  • Audix

Audix – M55WD

The M55WD is an innovative, hanging ceiling microphone system designed for applications where aesthetics, sound quality, and ease of installation are critical. All electronics are fully integrated with high sensitivity and low noise. The signal output is balanced to eliminate RF interference caused by cell phones and mobile devices.

Installing the M55 requires just one 5/8-inch hole in the ceiling, with no additional tools needed. The M55's mounting hardware easily adjusts the hanging height up to four feet from the ceiling surface without removing ceiling tiles and allows for fingertip height adjustment and roHigh output allows distance miking.

Features

  • Optimized for voice recognition
  • Low-noise preamp circuitry
  • Immunity from RF interference
  • Two-color LED status indicator
  • RJ45 connectors for plug-and-play integration with the Audix Dante | AES67 Integrated Microphone System
  • No external power adaptor required
  • Designed, assembled, and tested by Audix in the USAtation control. An optional aiming clip (MCHANGER) easily makes any additional angular adjustments

Dante Made Simple - By Audix

The M70WD is designed exclusively for the Audix Dante | AES67 Integrated Microphone System , which delivers high-quality audio and all microphone functions - including on-off contact closure and LED status indicators - through a single CAT5 - CAT7 cable with RJ45 connections. This simple configuration eliminates wiring errors, accelerates installation, and reduces cost. And like all Audix microphones in the system, the gain structure is optimized for its intended use, providing quality audio at the DSP. The result is true plug-and-play installation.

    Microphones
See the product
DMS-1021CD
  • ZenWin

DMS-1021C

Features:
  • Adopting Zenwin's original digital conference technology, in compliance with the IEC60914 international standard
  • Exquisite and elegant countertop structure, ergonomic and modern, mainly used in high-end conferences and other professional occasions
  • Using zinc/aluminum alloy material, anodizing process, CNC precision machining high gloss edge
  • Easy to adjust, durable, small, and can be repeatedly swung. The goose neck can be bent to quickly and freely fix the microphone head in the appropriate position
  • The conference unit is equipped with a 2-inch color screen displaying conference mode, conference unit ID number, and chairman/representative function;
  • The microphone gain can be independently adjusted on the computer management software to make speakers of different volumes speak more smoothly;
  • Double layered windproof sponge cover can reduce the occurrence of indecent jet and other wind sounds during speech
  • Built in high-performance DSP audio chip, optimized audio signal, restored vocals, and excellent sound quality
  • Two color LED indicator light, green for speaking, flashing red when applying for speaking and setting ID;
  • The unit comes with a 1.5-meter Category 6 shielded Ethernet cable; 11. The ID number of the microphone unit can be assigned to the conference unit ID through the ID switch of the conference host;
