ZW-D2
Features
- It can display the current IP and other settings.
- Gain and other parameters can be set in the software
- Connect directly to the network using Ethernet cables
- Dante devices can be controlled in remote mode
- Dual port backup, PoE power supply, and independent external power supply
- 4 microphone/line input with phantom power supply, 4 line outputs
- The entire scalable Dante system has 512 bidirectional audio channels
Technical specifications:
- Frequency response 20-20kHz
- Input impedance of 2k ohms (microphone); 68 ohms (line)
- Output impedance of 100 ohms (microphone); 100 ohms (line)
- High pass filtering at 80 Hz, 18 dB/octave
- Sampling rate 48K
- Power consumption less than 5w
- Total harmonic distortion<0.01%
Interface:
- (Input) Balanced audio, quick connect to 4 header ports
- (Output) Balanced audio, quick connect to 4 header ports
- 1 independent power interface
- 2 Dante network interfaces
- Phantom power supply+48V
- Power supply requirement+48V DC or IEEE802.3af PoE
- Dimensions 44mm x 210mm x 166mm
