Wohler – OPT-DANTE (iAM)

Dante Interface Cards

More details

Similar Products

apogee-symphony-io-mk-ii-dante-option-card
  • Apogee

Apogee – Symphony I/O MK II Dante Option Card

With the Symphony I/O Mk II Dante option card and a simple ethernet cable, Symphony I/O Mk II can be easily connected and shared across post production, broadcast, live sound or recording studio networks, unleashing legendary sound quality on the world’s most popular audio-over-IP solution.  With the Symphony I/O Mk II Dante option card and a simple ethernet cable, Symphony I/O Mk II can be easily connected and shared across post production, broadcast, live sound or recording studio networks, unleashing legendary sound quality on the world’s most popular audio-over-IP solution. The Symphony I/O Mk II Dante option card also includes Pro Tools connectivity for integration of Pro Tools | HD systems into a Dante network environment. No other Dante-enabled audio interface offers this level of quality, flexibility and modularity.
    Dante Interface Cards
  • Dante Ch: 64x64
  • 24-bit
See the product
musicrown-dmh-dsp
  • Musicrown

Musicrown – DMH DSP

Musicrown's DMH DSP is a Dante interface card.  Musicrown's DMH DSP is a Dante interface card.
  • 32 bit SHARC DSP, 96kHz sampling rate, 24 bit AD/DA convert.
  • 8X8 core matrix, which includes 4 local input channels, 4 local output channels, 4 Dante input channels and 4 output channels.
  • Dante digital network port configuration is a double standard network interface, which fully supports the function of unite switching and hot backup. Digital audio channel can support 4IN/4OUT, using 24-bit precision and extremely low network latency.
  • Input including low-cut, 5 band PEQ, noise gate, gain, mute, phase, link adjustment and volume adjustment.
  • Output including X-over, 7 band PEQ, Gain, mute, compressor/limiter, phase, delay and link adjustment and volume adjustment.
  • All PEQ Gain, bandwidth, frequency continues adjustment. Type can be select by PEAK, H-SHELF, L-SHELF, LOW CUT, HIGH CUT, ALLPASS1, ALLPASS2.
  • All high cut, low-cut filter type can be select by Butterworth, Link witz-Riley, Bessel, slope can be chosen.
  • Noise gate's threshold, time, ratio can be adjustment for inputs, compressor, limiter, ratio, time can be adjustment for outputs.
  • Maximal delay time 680mS for all input/output channels.
  • Inside single generator(pink, white noise and 20~20K sine wave, amplitude adjustable ).
  • Hardware with 7 channel I/O monitor, 4 channels support AD sampling potentiometer, 3 channels I/O support temperature, level, fault sampling function.
  • 21 user presets, device and each preset can be save and recall alone. Password protection function for high level applications.
  • PC software support Dante port link, and display automatically searched IP address at rear time. One-button linkage easy for use’s operation more convenient and swift.
  • Module power supply is DC5V 2A.
  • Module size is 135mmx52mm.
DMH Series:
  • DMH 2.0 - 2 analog input, 2 Dante output
  • DMH 0.2 - 2 analog output, 2 Dante input
  • DMH 2.2 - 2 analog input/output, 2 Dante input/output
  • DMH 4.0 - 4 analog input, 4 Dante output
  • DMH 0.4 - 4 analog output, 4 Dante input
  • DMH 4.4 - 4 analog input/output, 4 Dante input/output
    Dante Interface Cards
See the product
  • Adam Hall Group

Adam Hall – LD Systems X-EDAI

With the X-EDAI Ethernet & Dante Audio Interface expansion card, LD Systems complements the possibilities of the X-ECI Ethernet Control expansion card with a Dante Audio Interface with four inputs and outputs. Thus, X-EDAI offers both remote control and access to the DSP settings of LD Systems IPA DSP installation power amplifiers as well as easy integration of the IPA series into existing Dante audio networks.

In conjunction with LD Systems QUESTRA® software, the X-EDAI interface card provides flexible and effective configuration and control of fixed audio installations of various sizes - whether in hotels, restaurants, shopping centres, sports facilities, office environments and more.

The X-EDAI Ethernet Control expansion card has two IP network ports: While the 100 Mbps Ethernet port provides control and DSP access for the IPA installation power amplifiers, the second port can be used to transmit and receive four incoming and four outgoing Dante audio channels. The configuration and routing of the Dante audio channels is done as standard in the Audinate Dante Controller software.

Furthermore, the X-EDAI expansion card has a status LED and an IP reset button for quick and easy troubleshooting. Thanks to the card's asymmetrical pin arrangement, accidental incorrect installation of the interface card in the IPA housing is impossible.

Via the QUESTRA® software, system integrators can access all DSP settings of the IPA installation power amplifier. The possibilities range from signal processing at the input (preamp, compressor, etc.), signal flow in the matrix mixer, output processing (EQ, dynamics, delay, polarity, mute) to priority settings and preset management. In addition, customised control panels can be created in the QUESTRA® software, which can be used by end customers on smartphones, tablets or computers (via the QUESTRA® Panels app) for convenient control of their system.

    Dante Interface Cards
  • Dante Ch: 4x4
See the product
