Flex Focus loudspeakers employ shaded line array technology with ribbon HF drivers to extend sound projection in longer meeting rooms. Their Frequency response (120-20,000 Hz ±3 dB) has been optimized for speech intelligibility.
Flex Focus Vertical Arrays are available in two configurations. A standard version with loudspeakers oriented for monitors which are mounted at a normal viewing height and an LAC (Lowered Acoustic Center) version for monitors which are mounted above normal viewing height.
Flex Focus loudspeakers are also available in three powered configurations, each with 100- watt class D amplifiers:
Dante-enabled models include:
The speaker's power is supplied via POE+ (Power over Ethernet) or DC19V power supply, available at option. The speaker includes a Class-D audio power amplifier which provides effective use of power.
The audio network system is also compatible with AES67 which makes this speaker system flexible and compatible with other audio network systems.
The system comes with 6.25” coaxial 60W loudspeaker driver, MNS-6AXXCS-1P [MONISMS Model:MNS-6A11CS-1P / MNS-6A12CS-1P / MNS-6A22CS-1P] has excellent dispersion, wide bandwidth and smooth frequency response which makes this the top choice for today’s overhead commercial applications.
This assembly can be used in wide range of projects for paging and background music applications.
MNS-6AXXCS-1P is powered by standard POE+ and has a MAX power of 30 watts. If there is not POE+ source available, it can be powered through an external 19VDC power supply.
[Model:MNS-6A11CS-1P] 1 Channel, Only Master DANTE Speaker.
[Model:MNS-6A12CS-1P] 1 Channel, Reserve Additional Passive Speaker Terminals.
[Model:MNS-6A22CS-1P] 2 Channels [One Channel for Master Speaker, Another Channel for Passive Speaker], Reserve Additional Passive Speaker Terminals.
This speaker is specially designed for PA systems based on Dante audio networks. It is suitable for installation into a lightweight ceiling.
Network Enabled Loudspeaker by Dante™
Power Supply via POE+ or External 19VDC Power Supply
Full IEEE 802.3AT[30W] Compliance, High-Efficiency Synchronous Rectification Solution
Efficient CLASS-D Audio Audio Amplifier
Using 6-layers PCB design helps optimize reliability, EMI, EMC, heat dissipation, SNR, etc.
1*RJ45 Connection for Audio from POE Ethernet
Dante Domain Manager and AES67 Support
CE / EMC / LVD/ RoHS Passed
