The Bittner 4Xe power amplifier is available in 2 models, the 4X 1200e and 4X 2000e (with 4 x 1200 watt and 4 x 2000 watts @ 4 ohms respectively), and offers front controls, analog or digital inputs, XLR or Phoenix input connectors, Speakon or Phoenix output connectors – the concept of the 4X is as flexible as its applications. Also available are audio networking via Dante™ and control via Ethernet (with SXL II) offering worldwide diagnostics and maintenance via the Internet
The 4Xe and the rear control version, the 4Xi, both offer the following specifications:
- Up to 4x 2000 W in only 2 RU
- Impedance measurement
- Selectable Clip Limiter (hard/soft)
- 4-channel Dante Inputs
- SXL II Dataport (RS485)
- High Tech SMT Design
- Excellent sound and superior impulse response
- 2 separate stereo amplifiers
- Ready for 2 Ohm operation
- Protection Circuits: DC, LF, HF, Thermal, Short Circuit, Current Limiter, 3 ms Muting Delay
- XLR inputs and Speakon outputs (e version)
- Phoenix in- and outputs (i version)
- High-End switched power supply with PFC
- LED indicators for SIGNAL, CLIP, PROTECT, POWER
- Temperature controlled, variable speed low noise fans
- Digital wear-free Volume Controls (can be operated manually)
- Selectable Stereo/Bridged Mode
- Softstart
- Sequential Remote Power On
- 2 Alive Contacts
- 3 Years Warranty
