I/O Interfaces

Model 5682

The Model 5682 units are a specialized interface that allows two independent audio-over-Ethernet networks to be interconnected. One network supports the applicable SMPTE® ST 2110 standards while the other network supports Dante®. Two versions are available. The Model 5682-01 allows linking (in each direction) of up to 32 ST 2110-30 audio channels (at 48 kHz sample rate) with 32 Dante channels (at 44.1 or 48 kHz sample rate) or 16 Dante channels (at 88.2 or 96 kHz sample rate). The Model 5682-02 allows linking (in each direction) of up to 64 ST 2110-30 audio channels (at 48 kHz sample rate) with 64 Dante channels (at 44.1 or 48 kHz sample rate) or 32 Dante channels (at 88.2 or 96 kHz sample rate). The Dante interfaces support AES67 and the Dante Domain Manager™ application. Each unit mounts in one space (1U) of a 19-inch rack and is powered by 100-240 V, 50/60 Hz. Units can also be powered by an external source of 12 Vdc.
