MCS06 Ceiling Mic-Speaker


More Details

Similar Products

  • Sound Devices

A20-Nexus

SpectraBand  SpectraBand technology delivers a tuning range of 470 – 1525 MHz in a single unit – an industry first. Experience ultimate flexibility as you find open spectrum away from the crowded UHF TV band. The included A20-Monarch antennas can receive the entire 470-1525 MHz range, keeping your kit small and tidy. NexLink  Control your A20-Mini transmitter using the built-in long range remote control link. NexLink’s advanced long distance modulation reaches even farther than the A20-Mini’s long-range audio transmission. Network away  You’ve got options. Configure your A20-Nexus for Dante audio, use the built-in web server to control the receiver using the web browser on any computer, tablet, or phone, and even power the A20-Nexus remotely using Power-over-Ethernet (PoE).    Real time spectrum analysis  The days of waiting for a frequency scan to complete are over. Instantly visualize the fluctuating RF spectrum around you in real time – while running all channels of the audio.    GainForward  With the A20-Mini’s GainForward Architecture, easily set the Mini’s gain, low-cut, and limiter directly on your A20-Nexus or mixer-recorder. This immediate, local control of gain means never having to adjust the gain on the transmitter again. Go cableless . Thanks to its half-rack size, the A20-Nexus is equally at home in a rack, in a bag, or docked to an 8-Series mixer recorder for a cableless kit.    Long range  The A20-Nexus and A20-Mini deliver the longest transmission distance of any system on the market.¹ The state-of-the-art, 100% digital long-range modulation offers the same great audio quality (10 Hz – 20 kHz) as our Standard modulation scheme with a longer range for both line-of-sight and heavy multipath transmission.    Shoot for the stars  The A20-Nexus joins the growing lineup of Sound Devices Astral™ wireless products. With industry-leading features like SpectraBand, GainForward, NexLink, long range modulation, real time spectrum analysis, and more, the Astral Series pushes the bounds of wireless audio.
    Microphones
201991817125
  • BARE

BARE – Microphone System

Features
1. Advanced modular design, four groups of receiving modules, each group has a built-in independent CPU processing system to complete audio processing and transmission.
2. Ultra-high-bandwidth UHF 600MHZ-700MHZ, suitable for occasions that require a large number of microphones, making it easy to form a wireless conference microphone system.
3. Superb reception, overcome long distance and complicated field environments.
4. Use Ethernet cable to connect directly to the network-no need to add and solder audio cables.
5. Can control Dante routing and settings through a computer
6. The entire scalable Dante system has 512 two-way audio channels
7. Both the network volume and the receiver volume can be adjusted separately.
Technical parameters:
IF frequency: first IF: 110MHz, second IF 10.7MHz
wireless interface: BNC / 50 ohm
sensitivity: 12 dB (80dBS / N )
Sensitivity adjustment range: 12-32 dB
spurious suppression: ≥75dB
Maximum output intensity: +10 dBV
Frequency range: 600-700MHz
Modulation mode: FM
adjustable range: 50MHz
Number of channels: 100 or 200)
Channel interval: 250 KHz
frequency stability: within ± 0.005%
dynamic range: 100dB
maximum frequency deviation: ± 45KHz
audio response: 80Hz-18KHz (3dB)
comprehensive signal-to-noise ratio:> 105dB
Comprehensive distortion: ≤0.5%
Working temperature: -10 ℃ ~ + 40 ℃

    Microphones
