The Eclipse HX-Delta is a three rack unit (3RU) matrix intercom system frame provided with 2 Central Processing Unit (CPU) cards and 2 external power supplies.
The Eclipse HX-Delta is a three rack unit (3RU) matrix intercom system frame provided with 2 Central Processing Unit (CPU) cards and 2 external power supplies. The frame has slots for 4 I/O interface cards and 3 interface modules. This compact matrix frame offers the potential to connect users over dedicated CAT5, IP infrastructures (LAN, WAN and Internet),
The Eclipse HX-Delta is a three rack unit (3RU) matrix intercom system frame provided with two Central Processing Unit (CPU) cards and two external power supplies. The frame has slots for four I/O interface cards and three interface modules. This compact matrix frame offers the potential to connect users over dedicated CAT5, IP infrastructures (LAN, WAN and Internet), Fiber networks and integrate wireless beltpacks. The HX-Delta can also interface with external sources including 4-wire audio, partylines, telephone lines and MADI, all of which can be seamlessly routed to user key panels or beltpacks. Up to 64 Eclipse HX matrices can be connected to form a single networked installation.
Eclipse HX-Delta Features:
- Compact 3RU system frame with slots for two CPU cards, four interface cards and three interface modules
- Up to 256 internal ports
- Dual external PSU for redundancy; dual cooling fans
- Alarms for frame temperature, external PCU failure, and fan failure
- Front to rear LAN / Panel patch
- Networking/Linking options include 4-wire, Fiber, IP, MADI, E1/T1, GPIO, DANTE and AES67
- Seamless integration with FreeSpeak II Wireless Intercom and IP Communication Panels
