The PMQ series are professional 100V
quad channel power amplifiers, providing a new standard for premium
sound 100V amplification in public address applications. Their advanced
features and availability in different output powers provide an enormous
flexibility for numerous applications.
The PMQ600 is a four channel Class-D
100V power amplifier with an output power of 600 Watt for each channel.
The WaveDynamics™ DSP processor combination with the 2.5” LCD display
gives an unmatched user experience with intuitive functions overview for
easy configuration.
Acoustics can be optimized using the
filters selectable between Low / High & Band Pass and the 7-Band
equalizer both with adjustable frequencies and Q-factor. Other provided
functions are delay and dynamic bass boost. These settings can be custom
configured using the front panel of the amplifier, whereby access can
be given on two different levels (User & Administrator) using
password or USB-key protection.
Configuration is made simple by the
loudspeaker presets and full system configurations which can be selected
from a library and uploaded with a USB flash drive. This ensures the
best acoustical performance with a ‘bullet-proof’ loudspeaker
protection.
A great input flexibility and source
compatibility is offered by the input selection matrix and the XLR and
terminal block signal connections. System integration is made easy using
the RS-232 control port. Optional Dante™ interface is available for the
WaveDynamics™ amplifiers. The installation of this network interface
allows receiving and sending of low latency, high quality audio over a
standard Ethernet network.
