• Receives audio channels from other Dante-enable devices
• Powered by PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at)
• Built-in power amplifer, digital signal processor, 5-band parametric
equalizer, parameter presetting, volume and mute control
• Discoverable and controllable over a standard Ethernet network
• Offers overload protection
• Dante Controller software tool for managing all audio operations
The digitally controlled line arrays Ascolto® are equipped with high-quality 2,5” neodymium loudspeakers, capable to spread perfectly voice as well as sound instruments. They can handle higher power applications, delivering great tone at any volume levels. Each Ascolto® digital line array contains a set of custom-designed, fully-programmable 135-MHz, 48-bit DSPs where high precision 76-bit accumulators ensure the bit resolution for a total quality in digital audio processing such as beam filtering and audio equalization.
The Ascolto LH1625 is unique for its acoustic directivity, extremely selective and capable of reaching deep space. The Ascolto LH1625 is particularly suitable to ensure an extended coverage in large environments, where it needs simultaneously a very incisive beam and a bright tone.
Ascolto LH1625
enhances the quality of the sound;
improves environment with acoustically difficult characteristics;
focuses the sound energy directly to the public, minimizing the effects of the sound
reflections of the ceiling and the side walls;
fulfills all aesthetic and architectural requirements;
distributes capably audio in cathedrals, churches, mosques, theaters, auditoriums, airports,
railway stations and in general everywhere it is necessary acoustic precision and reliability.
The digitally controlled line arrays Ascolto® are equipped with high-quality neodymium loudspeakers, capable to spread perfectly voice as well as sound instruments. They can handle higher power applications, delivering great tone at any volume levels. Each Ascolto® digital line array contains a set of custom-designed, fully-programmable 135-MHz, 48-bit DSPs where high precision 76-bit accumulators ensure the bit resolution for a total quality in digital audio processing such as beam filtering and audio equalization.
The Ascolto LH1625 possesses the innovative Anti Reverberation System ARS®, capable of increasing the voice intelligibility in reverberant environments. ARS conveys uniformly acoustic energy on the lower part of the audio beam and reduce drastically the audio emission upwards, attenuating significantly the acoustic reflections related to ceilings.
AVE Line Array User Control® is a sophisticated software application that uses a complex proprietary algorithm to calculate accurately SPL distribution of Ascolto® Digital Line Arrays from their EASE® models. It allows the user to select the appropriate dispersion pattern and transfer aiming and filtering parameters to the digital line array through the dedicated network.
The AVE IRC Infrared Remote Control lets you control the configuration settings even if a host computer is not available.
The LH1625 is optionally available with Dante card. Thus the LH1625 can be integrated in an existing speaker system or in a Dante network.
