This product has reached "end-of-life" and is discontinued by the manufacturer
The 1542NA-D is a compact power amplifier module capable of driving small loudspeaker loads in a GLOBALCOM® system.The 1542NA-D provides two outputs, each with 4 watts of power into an 8Ω load. This makes the module ideal for powering small zones that are made up of only a few low-powered loudspeakers.The audio inputs to the module are through the Ethernet audio network and are configured from the GLOBALCOM® System Management Center. The 1542NA-D model allows the use of Dante™ audio networking protocols.The 1542NA-D is powered using standard PoE and draw a maximum power of 13 watts. If PoE equipment is not used, an input is provided for an external +48VDC power supply. A green power indicator LED is included to show that the unit is powered on. Each channel has a green LED indicator that illuminates when signal is present and a yellow LED to indicate clipping. Another yellow LED illuminates to indicate that the device is in thermal overload. When this condition occurs, the device will stop passing signal until the condition has cleared.The amplifier is provided in an enclosure that either mounts to a DIN rail or is screwed down on a panel or wall to allow for convenient installation in remote closets close to the loudspeaker zone.Features
- Available in single-channel or two-channel configurations
- Available with Dante™ audio network interface
- Control and configure using a web browser and GLOBALCOM® System Management Center
- Settings storage in non-volatile memory
- Full integration with theAtlasIED GLOBALCOM® vACS
- Utilizes IEEE 802.af Power over Ethernet (PoE)
- Removable connectors for easy installation
- Rugged DIN-rail or panel/wall mount enclosure
