WM-6P

Speakers

More Details

Similar Products

6301DT Broadcast Studio
  • Fostex

Fostex – 6301DT

After over 35 years as the industry standard in active confidence monitoring, the Fostex 6301 has officially entered the networked-audio age with the release of the 6301DT, the world's first ultra-rugged Dante-enabled Fostex monitor. With the same physical dimensions as the current 6301N, the 6301DT finally answers the challenge of how to quickly and easily set up a portable or fixed monitoring solution on a Dante network. Broadcast facilities, studio, conference rooms, houses of worship, medical centers, theatres, and installations of all types can now benefit from the rock-solid and trusted tool of audio professionals everywhere.

Main Features

• 20W Class-D power amplifier for higher output level and less power consumption.

• Dedicated 4-inch full range driver for clear audio reproduction.

• RJ45 Dante & 1/4” TS analog inputs.

• Supports sample rates up to 96kHz via Audinate’s Ultimo chip.

• Two channels of monitoring in one monitor: acts as a two-channel device on the Dante network, with a switch on the back panel to select channel 1, 2 or 1+2 (mixed) for output.

• Ultra-rugged die-cast aluminum enclosure.

• Recessed front-panel knob, switch & speaker grille to prevent inadvertent damage in case of a fall.

• Switching power supply accepts 100 V to 240 V AC.

• Physical dimensions identical to the rest of the 6301N series for easy upgrade.

• Optional EB-6301 mounting bracket allows easy surface-mounting at any angle.

Specifications

Speaker Section:

Enclosure type:                  Closed

Unit:                                    4” Full Range

Frequency response:         70 Hz – 15k Hz

Sound Pressure Level:       85dB / W (1m)

Maximum SPL:                   98dB

Amplifier Section:

Inputs:                                Dante Input (RJ45), 1/4” TS Phone (unbalanced)

Analog Input Impedance:   10k ohm or more

Rated output:                      20W

Distortion (T.H.D.):             0.05% (1kHz / 1W output)

Residual Noise:                  -65dBV

Input Sensitivity:                 Analog (unbalanced): -14 dBV (0.2 Vrms)

General:

Dimensions:                       120 (W) x 189 (H) x 120 (D) mm

Weight:                               2.3kg

Power Requirement:          AC 100 – 240V (50/60Hz)

Power Consumption:          10W

    Speakers
See the product
  • Yamaha

DZR15-D / DZR15-DW

The DZR15-D is a Dante-equipped 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 139dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR15-D realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
  • 2-way powered loudspeaker with a 2” HF and a 15" LF
  • Maximum 139dB SPL and 34Hz-20kHz frequency range is ideal for today's professional audio demands
  • High power 2000W Class-D amplifier module
  • 96kHz DSP and FIR filter for true high-resolution sound with super low latency
  • Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
  • Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
  • Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
  • D-Contour and highly reliable protection circuits
  • Floor monitoring setting enables mirroring configuration
  • Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
  • Optional speaker cover (SPCVR-DZR15)
  • Rotatable horn and variety of U-bracket options (UB-DZR) for rigging allow for very flexible setup and speaker placement
  • Durable Black or White finish
    Speakers
See the product
amk-DS82-B|amk-DS82-B
  • AMK

AMK – DS82-B

The AMK DS82-B loudspeaker assembly is powered by a POE+ network amplifier with Dante™ input. No external power supply is required. The speaker includes a Class D amplifier which provides efficient use of power. The assembly comes with AMK's CX 802, highly efficient coaxial loudspeaker. This is a 2 Channel System. The AMK DS82-B loudspeaker assembly is powered by a POE+ network amplifier with Dante™ input. No external power supply is required. The speaker includes a Class D amplifier which provides efficient use of power. The assembly comes with AMK's CX 802, highly efficient coaxial loudspeaker. This system will solve the issue of having to provide a separate amplifier or I/O interface for speaker installations. This is a 2 channel system. One PoE amplified speaker can power a total of (2) speakers, one active and one passive speaker. The passive speaker installed at different zone for different channel of broadcasting. The CX802 loudspeaker driver has excellent dispersion, wide bandwidth and a smooth frequency response which makes this the top choice for today’s overhead commercial applications. This assembly can be used in wide range of projects for paging and background music applications. The DS82-B is ideal for hotels, education, hospitals, retail stores, performing art centers, restaurants, airports, houses of worship, and board rooms.
