The CP124 beam forming array module with internal passive crossovers between LF and HF way. It is intended as basic beamforming column loudspeaker for the CADAC product range. The combination of mapping optimization and direct array definition is the most comprehensive and powerful loudspeaker management system on the market. The CP124 is a self-powered 2-way high-end beam forming array loudspeaker, which features 12 x 4" wideband woofers and 12 passive crossovers, for 36 x 1" dome tweeters. Due to the fully integrated connection hardware, the column can be stacked to realize larger systems with up to 14 meters of acoustic length. Internally, one CP124 has 12 amplifier and 12 DSP channels. The CADAC DSP-core module platform is integrated with the amplifier section into the loudspeaker. Cabinets are electrically connected by the CADAC C-Link audio and command interface. The CCP control and prediction software can connect to the array via LAN for command and control, Auto-EQ and to calculate sound prediction on listener areas. With the CMAP (mapping optimization mode), the vertical dispersion can be adjusted and optimized according to the listener area.
