The D7-2 Digital Hearing Loop Amplifier represents the global benchmark for digital audio induction loop systems. Featuring all the benefits of the Standard D14-2 driver with added Dante Input for additional Network Audio.
The D7-2 Digital Hearing Loop Amplifier represents the global benchmark for digital audio induction loop systems. Featuring all the benefits of the Standard D14-2 driver with added Dante Input for additional Network Audio.
The D Series range consists of 4 class 'D' drivers (3 dual loop output and 1 single output models); meaning a 60%+ increase in energy efficiency over existing solutions. Drivers feature capacitive touch front panels with intuitive menus, built in test signals, and are fully networkable with a Wi-Fi accessible standard browser based control panel for remote set-up, monitoring and email alerts.
The D7-2 Dante features 7 Amps per loop output respectively plus ample voltage headroom, making it the most flexible solution on the market, suitable for a huge range of applications.
In another first for high-power Class D Induction Loop drivers, installation can be performed with total confidence, as unique multi-stage filtering ensures compatibility with both other system equipment and global EMC regulations. The D Series also boasts Dual slope Metal Loss Control that caters for a wide range of metal loss frequency characteristics.
Features
- Dante Input for additional Network Audio
- Single or dual output options. Dual outputs featuring accurate and stable 90° phase shift
- Networkable with remote browser interface
- Digital display & intuitive 'touch' menu system - 3 modes; Main, Status & Quick
- Highly energy efficient Class-D amplifiers with low heat dissipation
- Up to 2 x 650m2 Perimeter Loops area coverage
- Up to 3,300m2 MultiLoop™ Low Loss area coverage
- Compact 1U rack mount unit with internal transformer for simple rack installation
- Optimised for speech frequencies with unmatched intelligibility & capable of high quality musical reproduction
- AGC & Dual Slope MLC
- Active status monitoring & remote fault reporting via email
- Data compliant with: IEC 62489-1 Standard
Applications include
- Lecture Theatres & Conference facilities
- Stadia, Sports Halls, Cinemas & Theatres
- Courts Rooms, Airports & Railway Stations
