FOR-A – Envivo Replay

Commentary Systems

More details

Similar Products

adx2400m-oblique-700
  • Lance Design

Lance Design – ADX-2400M

The ADX-2400M MADI Network Interface accepts a MADI stream as its local inputs, and outputs a MADI stream as its local outputs, making integration with the truck's or studio's audio system fast and simple.

The 24 local inputs and outputs use 24 of the 64 available MADI channels, and may be configured to use channels 1-24 or 33-56. All other MADI channels pass through the unit. This allows two ADX-2400Ms to be used in tandem on a single MADI stream.

Both optical and coax MADI inputs and outputs are available. The optical I/O uses a standard SFP module, so it may be configured for multi-mode or single-mode fiber, with wavelength and power parameters of the customer's choice.

These units may serve as the 'truck end' of ADX networked announce systems, or with other 2400s for transmission or distribution, or to provide a network interface for other vendors' networked products.

    Commentary Systems
  • Dante Ch: 24x24
  • 24-bit
See the product
m236_ta_1200-1024x739|m236_ta_1200-1024x716
  • Studio Technologies

Studio Technologies – Model 236 Announcer’s Console

The Model 236 Announcer's Console is designed for on-air and live-event use by announcers and commentators who will benefit from high-performance microphone and headphone audio resources. Supports Dante audio-over-Etherent media networking technology and includes an extensive set of features. The compact tabletop unit uses the STcontroller software application for configuration. Seven pushbutton switches allow the user to control seven audio output channels: one main and six talkback. Two gigabit (GbE) Ethernet interfaces allow redundant Dante operation. Powered using a Power-over-Ethernet (PoE) connection or an external source of 12 Vdc.

    Commentary Systems
  • Dante Ch: 11x10
  • 24-bit
See the product
JOKER
  • RAmi Audio

RAmi audio – JOKER

The JOKER is a three-commentator unit. It includes all the features needed for sports commentators, such as making the antenna, sends and returns as well as monitoring talkback individually configurable.

The JOKER has an IP port and an embedded web server. This allows both the specific programming of the equipment in controls and secondly to take control of remote commands, without specific software.

• Three microphones inputs on balanced XLR, two commentators and a guest, with a phantom power supply 12 or 48 volts.
• “HELP MODE“ for talking to support engineer.
• Luminous ON AIR switches for the three inputs.
• Luminous switch to send Talback A and B for commentators 1 and 2 inputs.
• ON AIR output is muted when one of the talkback switch is pressed.
• The JOKER offers inputs/outputs (GPI/GPO) on a Sub-D 15 pin connector.
• IP mode even allows use in stand-alone.

    Commentary Systems
See the product
