Dante数字音频传输技术，无压缩、无损耗、极低延时；以网络IP化架构设计，实现网络化、数字化，具有传输距离远、无干扰及低损耗等特点；集网络传输、纯数字功放的全频音箱。以太网供电和音频数据传输整合，实现线缆布局简单化，且符合以太网工程规范；具有高效率高声能输出、出色的音质、完善的保护功能和良好的电磁兼容特性；自带DSP网络有源音箱可在PC端远程对有源音箱的EQ、喇叭两端电压、电流进行监测控制；具有完善的保护功能（短路保护、过流保护、过欠保护、直流保护、功率压限、温度压限、长期输出功率限制、削波限幅器；免去了AP插座和适配器，使工作环境更安全整洁；设备移动方便，可移到任何有局限网线的地方可使用；以网络IP化架构设计具有高扩展性和音频组网能力。
The digitally controlled line arrays Ascolto® are equipped with high-quality 3,5” neodymium loudspeakers, capable to spread perfectly voice as well as sound instruments. They can handle higher power applications, delivering great tone at any volume levels. Each Ascolto® digital line array contains a set of custom-designed, fully-programmable 135-MHz, 48-bit DSPs where high precision 76-bit accumulators ensure the bit resolution for a total quality in digital audio processing such as beam filtering and audio equalization.
The Ascolto AH3235 is unique for its acoustic directivity, extremely selective and capable of reaching deep space. The Ascolto AH3235 is particularly suitable to ensure an extended coverage in large environments, where it needs simultaneously a very incisive beam and a bright tone.
Ascolto AH3235
enhances the quality of the sound;
improves environment with acoustically difficult characteristics;
focuses the sound energy directly to the public, minimizing the effects of the sound
reflections of the ceiling and the side walls;
fulfills all aesthetic and architectural requirements;
distributes capably audio in cathedrals, churches, mosques, theaters, auditoriums, airports,
railway stations and in general everywhere it is necessary acoustic precision and reliability.
The digitally controlled line arrays Ascolto® are equipped with high-quality neodymium loudspeakers, capable to spread perfectly voice as well as sound instruments. They can handle higher power applications, delivering great tone at any volume levels. Each Ascolto® digital line array contains a set of custom-designed, fully-programmable 135-MHz, 48-bit DSPs where high precision 76-bit accumulators ensure the bit resolution for a total quality in digital audio processing such as beam filtering and audio equalization.
The Ascolto AH3235 possesses the innovative Anti Reverberation System ARS®, capable of increasing the voice intelligibility in reverberant environments. ARS conveys uniformly acoustic energy on the lower part of the audio beam and reduce drastically the audio emission upwards, attenuating significantly the acoustic reflections related to ceilings.
AVE Line Array User Control® is a sophisticated software application that uses a complex proprietary algorithm to calculate accurately SPL distribution of Ascolto® Digital Line Arrays from their EASE® models. It allows the user to select the appropriate dispersion pattern and transfer aiming and filtering parameters to the digital line array through the dedicated network.
The AVE IRC Infrared Remote Control lets you control the configuration settings even if a host computer is not available.
The AH3235 is optionally available with Dante card. Thus the AH3235 can be integrated in an existing speaker system or in a Dante network.
The Aimline PoE+ series includes column loudspeaker with an integrated power amplifier that uses Power over Ethernet (PoE+). There is no need for any additional power supply. Thanks to highly efficient power electronics and a specially developed power amplifier an output of 30 W / 60 W peak (when using a PoE+ supply) can be achieved. Two channels DANTE® are available with 10-Bd IIR filters, delay and the 24 internal presets offer all necessary configurations. It is controlled and monitored using the IP-based PAN C software.
All active AIMLINE digital systems can therefore be controlled via just one software interface.
Easy connection – just one cable
This system will solve the issue of having to provide a separate amplifier or I/O interfaces for speaker installations using just a single CAT cable over long distance. This assembly can be used in wide range of projects for paging and background music applications. The AIMLINE AL 4.1 PoE+ is ideal for hotels, education, huddle rooms, hospitals, retail stores, restaurants, airports, houses of worship, and boardrooms.
