It has 8 analog inputs and 8 analog outputs, as well as 8 Dante inputs and 8 Dante outputs, making it suitable for independent sound reinforcement systems as well as medium to large scale remote conferencing and local amplification scenarios.
| Mode | MA-1616Dante |
| Input Channels | 16 |
| Output Channels | 16 |
| Scenem anagement | 8 sets of pre -set scenes |
| Input channel features | Pre-amplification, signal generator, expander,compressor, automatic gain control, 5-section PE Q |
| Output channel features | 8-section PEQ, delayer, frequency divider, high - lowpass filter,lim iter |
| Sampling rate | 48kHz |
| Dynamic range from input tooutput | >110dB |
| Phantom power | DC 48V |
| Input common-mode reject ion | 75dBu @ +20dBu,60Hz |
| Channel isolation | 105dB |
| Frequency response | 20~20kHz (±0.5dB ) |
| Total harmonic distortion (THD+N ) | ≤0.005% @1kHz,+4dBu |
| Max. input gain | 54dB |
| Input impedance | 2KΩbalance |
| Output impedance | 100 ohm |
| Max. output level | 20dBu |
| Power supply | AC 110V~230V AC, 50Hz /60 Hz |
| Working temperature | 0-40℃ |
