BARE – AD-48


More details

Similar Products

  • Yamaha

DZR15-D / DZR15-DW

The DZR15-D is a Dante-equipped 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 139dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR15-D realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
  • 2-way powered loudspeaker with a 2” HF and a 15" LF
  • Maximum 139dB SPL and 34Hz-20kHz frequency range is ideal for today's professional audio demands
  • High power 2000W Class-D amplifier module
  • 96kHz DSP and FIR filter for true high-resolution sound with super low latency
  • Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
  • Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
  • Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
  • D-Contour and highly reliable protection circuits
  • Floor monitoring setting enables mirroring configuration
  • Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
  • Optional speaker cover (SPCVR-DZR15)
  • Rotatable horn and variety of U-bracket options (UB-DZR) for rigging allow for very flexible setup and speaker placement
  • Durable Black or White finish
    Speakers
  • Dante Ch: 2x2
  • 24-bit
pan-acoustics-pb-s-208_0|pan-acoustics-pb-s-208_0
  • Pan Acoustics

Pan Acoustics – PB S-208

The PB S-208 is an active subwoofer incl. DSP and network functionality. The PB S-208 is the low extension of the Pan Beam family. It is characterized by an unobtrusive design and a genuine and deep bass response. The PB S-208 can be operated in various cardioid applications. The PB S-208 is an active subwoofer incl. DSP and network functionality. The PB S-208 is the low extension of the Pan Beam family. It is characterized by an unobtrusive design and a genuine and deep bass response. The PB S-208 can be operated in various cardioid applications. Operated via a user friendly Windows software, the connec- tion to the computer occurs over an RS 485 network. With the help of digital signal processing, the sound and the delay time can be entered and controlled. The PB S-208 is equipped with two 8" HQ-Drivers and a digi- tal amplifier. The total amplifier power is 600 Watts (800 Watt peak) with a power consumption of 20 VA (normal) or 800VA (max).
    Speakers
FF1670
  • AVE

AVE – Ascolto FF1670

FF1670 performs 16-channel DSP beam filtering to steer the vertical radiation pattern, making column high directive and featuring main propagation lobe less dependent on the frequency.

FF1670 is equipped with 16 high quality, coaxial loudspeakers, each one mounting 4” neodymium woofer + 1’’ dome tweeter, capable to transmit perfect audio.

FF1670 uses 16 x 70 Wrms class-D audio amplifiers with excellent THD+N and high efficiency (90%) and completely protected against thermal over-load.

FF1670 mounts high-reliable, switching power supply (860 W peak) with universal input (90 – 264 VAC).

FF1670 has analog line input and built-in Dante input both.

FF1670 setup comes easy throughout the AVE Line Array User Control PC software, via RS485 connection.

AVE Line Array User Control includes:
• Beam tilting/broadening control;
• Anti-Reverberation System ARS.
• Delay control;
• 8-biquads user equalizer with high/low shelving and parametric filters;

FF1670 cabinet is aluminum extrusion and it is designed and manufactured in Germany.

    Speakers
