I/O Interfaces

Auvitran – AVDT-BOB-ADX8IO

AVDT-BOB-ADX8IO is a compact Dante analog break-out box with embedded Digital Signal Processing. It provides two state-of-the-art analog microphone preamplifiers inputs and two analog line outputs on XLR connectors, plus stereo AES/EBU input/outputs and four GPIOs on DB25 connector.

AVDT-BOB-ADX8IO is a compact Dante analog break-out box with embedded Digital Signal Processing. It provides two state-of-the-art analog microphone preamplifiers inputs and two analog line outputs on XLR connectors, plus stereo AES/EBU input/outputs and four GPIOs on DB25 connector.

Embedded DSP allows for full mixing of the four Dante inputs/outputs, the two analog inputs/outputs and the four AES/EBU inputs/outputs plus effects like parametric equalization, dynamic compression and fine pitch digital gain adjustment.

Four analog/digital GPIOs allows for hardware remote control of the device (e.g. volume control via potentiometer).

Three Gigabit switched ports allows for daisy-chained/star connection without any bandwidth bottleneck. Neutrik port provides Power-Over-Ethernet for direct power supply. SFP ports accept multi-mode or single-mode fibers, allowing to link devices on distances up to 20km.

The embedded dual core processor runs a Web 2.0 server with user-friendly interface for multiplatform remote control over IP (iOS, Android, Windows, Mac OS, Linux).

Accessories like long-ears kit allows for mounting of up to three AVDT-BOB on 1U 19” rack.
