Astro Design – IR7523

A portable video recorder that uses CFexpress as a recording media. This unit supports the recording and playback of 4K 120p images on a stand-alone basis, and by connecting multiple units, you can record and play video with any extended resolution and frame rate.


● 4K YCBCR 4:2:2 120p can be recorded on a stand-­alone basis
● A CFexpress TypeB card (sold separately) is used for recording media
● Compatible with fixed 1/6 compression recording
● Recording times are 20 minutes with fixed 1/6 com­pression when recording 4K 120p to 640GB CFexpress
● Supports relay capturing with dual slots
● Equipped with a function to slowly playback recorded 4K YCBCR 4:2:2 120p video at 60p or less
● Multiple video recorders can be connected for arbi­trary extended resolutions in units of 4K (extended in the future)
● Multiple-unit connected operation enables video recording at an arbitrary extended frame rate with 60p/120p as one unit (future expansion)
● Supports 12G/6G/3G/HD-SDI, HDMl2.0 (OUTPUT)
● Supports 25G/100GbE (future extensions/options),25GbE/100GbE complies with SMPTE ST 2110-10/-20/-30/-40
● Equipped with TIMECODE input/output terminals(LTC only)
● Equipped with MADI input/output terminals
● Equipped with 2 channels of analog audio input and output connectors
● Supports Audinate Dante
● Genlock(BB/3 Synchronization Signal) input is equipped
● Supports up to 32-channel audio (uncompressed, 24-bit) recording
● Equipped with both DC power input and AC power input
